CV Control with T7S Topside

Standard Feautures:
– Self-Standing Control
– Dual-Voltage (120V/240V) Operation*
– T7 Digital Topside
– Ozone Ready
– Circulation Pump Ready
– 2 Speed 1st Jet Pump Ready (Cord Included)
– 1 Speed 2nd Jet Pump Ready
– 1 Speed Aux Pump (Jet or Air) Ready
– 12v Spa Light Ready (Cord/Harness Included)
– Self-Standing Low-Flo 3/4″B Stainless Steel Heater with 5kW Titanium Heating Element, Specifically Designed for Use with Low-Flow Circulation Pumps – on a 4′ cable.

Dimensions:
– 8.5″ Tall
– 20.75″ Wide
– 6″ Deep

Included Topside Control:
T7 Command Center

T7 Topside Dimensions: 5″ x 2.5″

* Transformer is factory set to 240V incoming power, but can be easily converted to 120V (See C5 Installation Manual).

• The included T7S Topside requires only a 1.75″ hole saw to install!

• When installing
you simply need to program the topside to operate the components in
your customer’s spa!

NOTE: These units come standard with the cords for the light and a two speed
primary pump, if additional AMP cords are needed please check out the ‘Cords’ section of the store
(click here – link should open in a new window).

Don’t forget to take a look at the optional Topside Extension Plate
(click here – link should open in a new window)
if you are replacing a larger topside then the T7, and our 1/4″ Thermowell/Bushing (dry sensor well/housing)
(click here – link should open in a new window)
if the spa you are installing the control into doesn’t already have one installed.

These controls come standard with primary and secondary pumps wired for 240v, and all other components (ozone, circulation pump, aux pump, audio) wired for 120v. Voltages of these controls may easily be changed by moving the neutral wires at the power block in the control as needed (see C5 Installation Manual).
